The EV ceiling slimline button is a sleek and modern lighting option that comes in two colour options: white or silver. It is non-dimmable and features a single colour temperature option of 3K or 4K, and has a convenient screw-off cover for easy installation. The button can be screwed through the base for secure and stable installation, and its slimline design allows it to blend seamlessly into any room's decor. The button also comes in three different sizes, 14W, 20W and 28W, that can be chosen depending on the size of the room or the desired brightness level.

• Material - Steel backplate & PMMA diffuser lens
• Colour - White or Silver
• Shape - Round

Use:
• Application - Residential use
• Use - Interior
• Warranty - 3 years
• L70 - 36,000 hours
• Switching Capacity - 30,000
• IP Rating - IP20

Power:
• Voltage - 230V
• Driver - Built-in
• Double Insulated - No

Light output:
• Lamp Type – Integrated LED
• Wattage - 28W
• Lumens - 2200lm or 2450lm
• Colour Temperature - 4000K
• CRI - >80
• Beam Angle - 180°
• Dimmable - No

Product info:
• Type - LED Slimline Button

Physical size:
• Dimensions (mm) - 380Ø x 50H

Product Reference:
• Catalogue 2021 - Page 58
• Catalogue 2022 - Page 54


• Mounting - Surface mounted
